NI PXIE-5842 High-Speed Data Acquisition Module

In stock

The NI PXIe-5842 is a high-speed data acquisition module designed for precise measurements in test and measurement applications. It supports advanced signal processing and offers excellent performance in challenging environments.

Order Number:PXIE-5842

Brand:National Instruments

Model:PXIe-5842

Series:High-Speed Data Acquisition

Sample Rate:Up to 10 MS/s

Resolution:16-bit

Channels:4 Differential Channels

Input Range:+/-10 V

Interface:PCI Express x4 Gen 2

Compatibility:Compatible with NI software suite

Dimensions:187 mm x 117 mm x 44 mm

The NI PXIe-5842 High-Speed Digitizer offers unparalleled performance in a compact form factor, perfect for integration into existing PXI systems.

With its ultra-high sample rate of up to 2 GS/s and a wide bandwidth of 500 MHz, it is capable of capturing fast transient signals with remarkable precision.

This digitizer is equipped with 2 channels, providing flexibility in acquiring complex waveforms.

Its 8-bit resolution ensures detailed signal representation, while a deep memory depth of 256 MSamples allows for extended capture durations without compromising on fidelity.

The PXIe-5842 supports various trigger modes including software, external, and ECL, ensuring reliable signal triggering across a range of applications.

Connectivity through PCI Express provides seamless integration with PXI systems, enhancing system scalability and efficiency.
